Siglent SPS6150X Power Supply, Single Output, 100V, 50A, 1500W, Switch Mode, SPS6000X Series
Couldn't load pickup availability
Ask an expert!
Siglent
Siglent Technologies manufactures oscilloscopes, waveform generators, spectrum analyzers, and power supplies offering exceptional value and reliability for engineers and educators.
SPS6150X Single Channel Switch Mode Power Supply
Features and Specifications
- Programmable, switching DC power supply
- Single channel
- Rated voltage: 100V
- Rated current: 50A
- Rated power: 1500W
- Connect up to five SPS6000X chassis of the same model in parallel to expand the output power
- Load transient recovery time (Load change from 50-100%) < 2.5 ms
- Adjustable voltage and current slew rates
- Setting and readback resolution: 10mV, 10mA
- Remote Sense function to decrease lead resistance error
The SPS6000X Series is a programmable switching DC power supply with a wide range of single output and constant power features. This series includes two models, the SPS6225X and SPS6150X, which feature rated output voltages and currents of 200V / 25A and 100V / 50A, with a maximum output power of 1500W. Users can connect up to five SPS6000X chassis of the same model in parallel to expand the output power to meet different application requirements.
What's in the Box
- SPS6150X Power Supply
- USB Cable
- Quick Start
- Calibration Certificate
- Power Cord
- Output Guard
