TESTEC TT-SX 9002 Active Differential Probe 8000, 30 MHz
Couldn't load pickup availability
Ask an expert!
TESTEC
TESTEC designs and manufactures high-quality oscilloscope probes and accessories engineered for precision signal measurement across a wide range of bandwidths and voltage levels. Trusted by engineers worldwide, TESTEC delivers reliable performance at exceptional value.
Testec TT-SX 9002 Active Differential Probe
Features and Specifications
- Selectable attenuation settings of x20, x200
- Bandwidth 30MHz
- Input Impedance 5MΩ, 2pF
- Rise Time 14ns
- Max. Input Voltage +/- 140V (DC + AC peak) @ x20
- Differential Mode +/- 1400V (DC + AC peak) @ x200
- Rated 1000Vrms CAT III
- Input Leads Length (each) 55cm, BNC Cable Length 95cm
- Attenuation Selection Button & LED Indicators
- Power and Overload indicator LED
- 4 mm Sheathed Banana Plug Connectors
- Insulated BNC Male Output Connector
- USB-C Input Power Port
The Testec TT-SX 9000 Series High-Voltage Differential Probes enable standard earth-grounded oscilloscopes to measure floating signals, supporting up to 700 V (TT-SX 9001) and 1400 V (TT-SX 9002) in both differential and common mode configurations. Each probe offers adjustable attenuation—10x and 100x for the TT-SX 9001, and 20x and 200x for the TT-SX 9002—providing flexibility for various tasks such as analyzing power supplies and motor control systems. Designed for broad compatibility, these probes work with any oscilloscope featuring a 1 MΩ BNC female input and deliver bandwidths up to 30 MHz. Power options include USB ports on oscilloscopes, four AA batteries (not included), or a mains adapter.
What's in the Box
- 1x TT-SX 9002 Active Differential Probe
- 1x TT-SX GR 1 Probe Hook Pair (red / black)
- 1x TT-SX USB Power Cord, 100cm
