Lascar Electronics
SKU: 70047199 | MPN: DPM 702S
NEW

Lascar Electronics DPM 702S Panel Meter, LCD Display, 3.5 Digits, Dual Channel, 200mV d.c FSR

€94,57 inc. VAT
Available
Order Today - Ready to Ship Soon
Request a Quote

Ask an expert!

Email + 49 ( 0 ) 8104 6675 - 0

Lascar Electronics

Lascar Electronics develops data loggers, digital displays, and sensors for monitoring temperature, humidity, and voltage in industrial and commercial settings.

Dual 200mV LCD Voltmeter with Annunciator symbols. Completely Assembled & Tested.

  • 6.4mm (0.25“) Digit Height
  • Dual Channel
  • 200mV d.c. Full Scale Reading (F.S.R.)
  • Selectable Decimal Points
  • Auto-zero, Auto-polarity
  • Common Signal Ground
  • Annunciators

The dual channel 3½ digit LCD panel meter features 6.4mm (0.25″) digit height, 200mV d.c. full scale reading, auto-zero and auto-polarity. Connection is via a 10-way SIL pin header. The module is fitted into a panel via the bezel, window and clips provided. This product is ideal for those applications where “matched” readings are required, e.g.: voltage and current, temperature and humidity, etc.
